제품특징

한층 업그레이드된 심플한 디자인.
1.DN-600F의 차기모델 CD/MP3 PLAYER
2.CD-R/RW, MP3 플레이백 기능
3.싱코 레코딩 기능(DN-780R호환)
4.프로그램 플레이 최대99트랙
5.플래임 서치 기능(22아이템)

제품스팩
Features
CD-R/RW Playback compatibility
±12% Pitch Control
Instant Start
Direct Track Select Buttons
CD TEXT
Auto Cue (Preset Selectable)
Playback Mode: Single/Continuous (Preset Selectable)
Elapsed/Remaining Time
User Preset functions (22 items)
Wired Remote Control terminal
Stereo Mini jack
Synchro Recording to the DN-780R via RCA In/Out (Phillips RC5 compatible)
Shock Proof Memory (approx. 10 sec.)
Power On Play
Repeat mode (Single Track/All tracks/Program & Random Repeat)
Random mode
Frame Search (75 Frames Per Second)
Coaxial RCA Digital Output (SPDIF)
Headphone output
Other Features
MP3 Playback
Folder/Title search
Program Play: Max. 99 tracks
A (11 keys including 0/Clear) 10-key pad is provided for direct track selection or to enter up to 99 tracks for programmed playback.
General
Standard 19inch, 2RU Aluminum Front Panel
IR Remote Sensor
FL Tube Display
Optional IR hand held remote RC-U620
Optional IR wristwatch remote RC-41
Optional Wired Remote RC-620
Expanded Connection In/Out (RCA)
Cascade Function (Figure 1)
The ports (CASCADE IN/OUT) of multiple DN-C615 units can be linked by cables to enable continuous playback among the units.
Synchronized Recording (Figure 2)
The ports (EXT. SYNC IN/OUT) of the DN-C615 and multiple DN-780R units can be linked by cables to enable simultaneous recording by all DN-780R units. (Up to 20 units can be connected for continuous recording of the source.)

Specifications

Audio Channel
2 stereo channel

Digital Filter
8-times Oversampling Digital filter

Frequency Response
20 Hz - 20 kHz

Total Harmonic Distortion
0.007%

S/N Ratio
107 dB (A weighted)

Channel Separation
90 dB or more

Sampling Frequency
44.1 kHz (at Normal Pitch)

Analog Outputs (1 kHz, 0 dB playback)

Output level
2.0 Vrms, 10 kohms

Digital Output


Transfer and Connector
Coaxial (RCA)

Signal Format
IEC-958 Type II (SPDIF)

General


Power Supply
AC120V, 60 Hz

Power Consumption
13W

Dimensions
482 (W) x 88 (H) x 280 (D) mm
19.0 (W) x 3.5 (H) x 11.0 (D) inch
(2 Rack Units, Removable Rack Ears)

Weight
4.7 kg, 10.4 lbs
